EN 10357
EN 10357
Description:
Standard: EN 10357
Grade: 1.4301/1.4307, 1.4401/1.4404
Production: Inside bead removed, Pickled
Up to Request: Annealed, Polishing, Inside/Outside roughness
Specification :
Application of EN 10357 Tube: Food and chemical industry, brewery, water plant, or solar panels manufacturing
| Outside Diameter/ Thickness |
inch | 1” | 1 1/4” |
- | 1 1/2” |
2” | 2 1/2” |
3” | 3 1/2” |
4” | 4 1/2” |
| mm | mm/ gauge | 25.4 | 31.8 | 35 | 38.1 | 50.8 | 63.5 | 76.2 | 88.9 | 101.6 | 114.3 |
| 1.20 | - | ||||||||||
| 1.24 | 18 | ||||||||||
| 1.50 | - | ||||||||||
| 1.65 | 16 | ||||||||||
| 2.00 | - | ||||||||||
| 2.11 | 14 |
Tolerance of EN 10357
| Outside Diameter | Thickness | Length | ||||
| D≦168.3 | D3 ±0.75% or ±0.3mm Whichever is greater | T3 ±10% or ± 0.2mm Whichever is greater |
|
|||
| D>168.3 | D2±1.0% | |||||
